Description
Summary
A tensile testing machine is a machine used to test the strength and properties of materials, which works by utilizing mechanical and electronic principles to measure the physical properties of materials. In the testing process, the sample is clamped between two fixtures, and the physical properties of the sample are measured by applying tensile force or pressure as well as the corresponding measuring transducer, and the data during the testing process can be processed and analyzed by computer software and other means.
Features
（1）It utilizes high-precision sensors to accurately measure the tensile strength of slings and spreaders, thus ensuring that they can withstand sufficient loads. In addition, it has an easy-to-use interface that allows users to operate it with ease, thus improving work efficiency.
（2）In addition, the Spreader Slings Tension Tester is durable for long term use and low maintenance. Its compact structure and small space occupation can save a lot of space, so that users can easily install and use.
（3）All in all, the Spreader Slings Tension Tester is a very useful instrument for accurately measuring the tensile strength of slings and spreaders, thus ensuring that they are able to withstand sufficient loads so that accidents can be avoided. It has the advantages of accurate measurement results, easy-to-use operation interface, durable features, compact structure and small space occupation.
Main technical data
Maximum test force KN | ±10kN |
Effective width of column | 555mm(can be customized) |
Test space | 650mm(can be customized) |
Measuring range of test force | Dynamic 2% to 100% FS |
Test force resolution | 1/500000 yards |
Displacement measurement range | 150mm(±75mm) |
Displacement measurement resolution | 0.001mmm |
Displacement | Accuracy within ±0.5%FS from 1% |
